All product items
17
| Product ID | Name | Cross-section | Fire class | Package | In stock |
|---|---|---|---|---|---|
| 00001 | NHXMH-O | 2x1,5 RE | Dca | Coil | To order |
| 00002 | NHXMH-O | 2x2,5 RE | Dca | Coil | In stock |
| 00003 | NHXMH-J | 3x1,5 RE | Dca | Coil | In stock |
| 00004 | NHXMH-J | 3x2,5 RE | Dca | Coil | In stock |
| 00005 | NHXMH-J | 3x4 RE | Dca | Drum | In stock |
| 00006 | NHXMH-J | 3x6 RE | Dca | Drum | To order |
| 00007 | NHXMH-J | 4x1,5 RE | Dca | Coil | In stock |
| 00008 | NHXMH-J | 4x2,5 RE | Dca | Drum | To order |
| 00009 | NHXMH-J | 4x4 RE | Dca | Drum | To order |
| 00010 | NHXMH-J | 4x6 RE | Dca | Drum | To order |
| 00011 | NHXMH-J | 4x10 RE | Dca | Drum | To order |
| 00012 | NHXMH-J | 4x16 RE | Dca | Drum | To order |
| 00013 | NHXMH-J | 5x1,5 RE | Dca | Coil, drum | In stock |
| 00014 | NHXMH-J | 5x4 RE | Dca | Coil, drum | In stock |
| 00015 | NHXMH-J | 5x6 RE | Dca | Coil, drum | In stock |
| 00016 | NHXMH-J | 5x10 RE | Dca | Drum | To order |
| 00017 | NHXMH-J | 5x16 RE | Dca | Drum | To order |
Similar products
ym-o-(N)ym-j-500v.jpg)
Technical data
| Customs Tariff Number (code number): | 85444999 |
| Standard: | DIN VDE 0250-214 |
| Conductor material: | Copper |
| Insulation: | Cross-linked polyethylene |
| Filling: | Special halogen free rubber |
| Sheathing material: | Halogen free, self exstinguihing, flame retardant |
| Flame retardant: | IEC 60332-1, DIN-VDE 0482-332-1 |
| UV-resistant: | No |
| For outdoor use: | No |
| Max. temperature at conductor, °C: | Max 70 °C |
| Laying temperature, °C: | Min 5 °C |
| Operating temperature, °C: | -30 to +70 °C |
| Core identification: | Colours acc. HD 308 |
| Colour of outer sheath: | White |
| Unit of measurement: | Metre |
Application
Low-smoke, zero-halogen, flame-retardant building wire, for installation on and under plaster in dry and wet rooms, as well as in concrete (except for shaken, jolted, tamped concrete). For indoor use only, primarily in buildings with a high concentration of people and material assets.
Technical documents
| NHXMH Dca | Data sheet | Download |
