All product items
8
| Product ID | Name | Cross-section | Fire class | Package | In stock |
|---|---|---|---|---|---|
| 00001 | HDHp-O | 2x1,5 RE | Dca | Coil | To order |
| 00002 | HDHp-J | 3x1,5 RE | Dca | Coil | In stock |
| 00003 | HDHp-J | 3x2,5 RE | Dca | Coil | In stock |
| 00004 | HDHp-J | 3x4 RE | Dca | Coil | To order |
| 00005 | HDHp-J | 4x1,5 RE | Dca | Coil | To order |
| 00006 | HDHp-J | 4x2,5 RE | Dca | Coil | To order |
| 00007 | HDHp-J | 5x1,5 RE | Dca | Coil | To order |
| 00008 | HDHp-J | 5x2,5 RE | Dca | Coil | To order |
Similar products
ym-o-(N)ym-j-500v.jpg)
Technical data
| Customs Tariff Number (code number): | 85444999 |
| Standard: | EN 50525-1:2011 |
| Conductor material: | Copper |
| Insulation: | Special halogen free polymer |
| Sheathing material: | Special halogen free polymer compound |
| Flame retardant: | IEC 60332-1 |
| UV-resistant: | No |
| For outdoor use: | No |
| Max. temperature at conductor,°C: | Max 70°C |
| Laying temperature, °C: | Min 5°C |
| Operating temperature, °C: | -40 to +70°C |
| Core identification: | Colours acc. HD 308 |
| Colour of outer sheath: | White |
| Unit of measurement: | Metre |
Application
Halogen-free power supply conductors for installations in facilities where human life and property must be protected against fire (hotels, hospitals, schools, airports, underground and train stations, industrial installations); conductors to be laid in dry and moist rooms, over and in plasterwork, in brick walls and directly in concrete; only permanent installation possible; in outdoor or underground installations cables must be laid in cable ducts or tubes.
